Unitube Patchcords MM

Unitube Patchcords: Designed for Data Centers and High Density

Unitube patch cords are designed for environments where space is limited and connectors are positioned very close together – such as data centers, server racks, and high-density panels. The slim construction and use of PushPull connectors make it easy and safe to install and remove the cables, even in areas where traditional grips are not accessible.

At BBT fiberoptic, we offer both standard Unitube patch cords from stock and customized solutions with short lead times.
All cables are supplied with zirconia ferrules and LSZH jackets (Low Smoke Zero Halogen), and are individually tested according to the relevant specifications to ensure high performance and stability.

Specifications

MM 62,5/125, 50/125, (OM3, OM4)
Standard- & special cables
Interferrometer test
Fiber according to IEC11801
Psysical contact and Convex polishing
Produced and tested according to IEC 61755 Grade B & IEC 61300
Fire resistant according to IEC60794-2-30
All cables are individually packed

Specification	OM1	OM3	OM4
Insertion Loss Type	≤ 0,15dB	≤ 0,15dB	≤ 0,15dB
Insertion Loss Max	≤ 0,20dB	≤ 0,20dB	≤ 0,20dB
Return Loss (UPC)	≥50dB	≥50dB	≥50dB
Operation Temperature	-40°C ̴ +75°C	-40°C ̴ +75°C	-40°C ̴ +75°C
Storage Temperature	-40°C ̴ +75°C	-40°C ̴ +75°C	-40°C ̴ +75°C
Pull Tension	100N	100N	100N
